SC-300II
Single Turret Machines
View Product Video
Broucher Catalog
Features
High Rigidity and High Precision Going Back to The Roots 10-Inch Single Turret Machine
- Milling and Y-axis are standard.
- Massive box-way slides on all axes.
- Machine Weight 9,000kg.
- NT Manual Guide i (LUCK-BEI II) Option.
Y-Axis Travel ±60mm
- Milling motor power 7.5/3.7kW and max. speed 6,000min-1.
- Tailstock driven by NC or Automatic (knock type).
Specifications
| φ71mm | φ89mm(op.) | |
|---|---|---|
| Max. Turning Diameter | 360mm | |
| Max. Turning Length(Right Spindle Specs.) | 635mm | |
| Max. Turning Length(Tailstock) | 600mm | |
| Distance Between Spindles(op.) | 910mm | |
| Distance Between Centers(op.) | 713.5mm | |
| Bar Capacity | 71mm | 89mm |
| Chuck Size | 10″,12″ | |
| L Spindle Speed | 3,500min-1 | |
| L Spindle Drive Motor | 22/18.5kW | |
| Milling Spindle Speed | 6,000min-1 | |
| Milling Drive Motor | 7.5/3.7kW | |
