AS-200

BACK

Y-axis Milling standard ! Turning and milling with full power !

  • Space saving combined machine tool with Y-axis & Milling function(standard)
  • With Y-axis! Stroke: 82mm
  • With Milling function: 5.5/3.7kw, spindle speed: 6000min-1
  • Stong spidle motor: 15/11kw
  • High speed index! X-axis: 24m/min, Z-axis:36m/min, C-axis: 600min-1.
  • Turret: Max dodecagonal drum turret(Max.24station) or 15station
  • Number of milling tool (dodecagonal drum turret): 12
  • Number of milling tool (pentadecagonal drum turret): 15

    • Machine Specification

    Capacity
      12st 15st
    Max. turning diameter 340mm 280mm
    Max. turning length 300mm
    Distance between center 427mm
    Bar capacity 65mm(op.71mm)
    Chuck size 8"
    Axis travel
    Slide travel X 227.5mm 212.5mm
    Slide travel Z 320mm

    Slide travel Y

    		 ±41mm
    Spindle
    Spindle speed 4,500min-1　
    Spindle motor

    15/11ｋW
    Turret
    Number of turrets 1
    Type of turret head Dodecagonal Pentadecagon
    Number of index positions 12 15
    Driven tools
      12st 15st
    Spindle speed 6,000min-1
    Driven motor power 2.2/1.5kW
    Rotary system Simultaneous rotation
    Number of driven-tool station

    12

    		 15
    Tailstock(op.）
    Quill diameter/Quill stroke 70mm/80mm
    Quill taper MT-4（Rotating center）
    General
    Hight 1,850mm
    Floor space （L×W） 1,650mm×1,600mm
    Machine weight 3,200kg
