- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 15.7” x 15.7” (400 x 400mm)
- 28.9” x 24” x 24” (735 x 610 x 610mm)
- NST No. 40
- 35~13,000rpm (40~15,000rpm, 20~20,000rpm Opt.)
- 50 Pcs. (100,150,200,300 Opt.)
- 1.0 sec. /3.2 sec.
- 1,969ipm (50m/min) x 15,000deg/min
- 50KVA
Large Work Envelope. Workpiece Dia x Height – 27.6” x 37.8”
Positioning accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
Patented twin ballscrew/twin servo motor driven axis drive system
Highest grade meehanite cast iron construction with solid box ways
4-Step gear driven 13,000rpm spindle delivers high torque & fine finish capability
Intelligent advanced control system with ballscrew cooling for thermal stability
Full 4th axis rotary table with high resolution rotary scale (Pos ±7.5 arc/sec)
