- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 19.7” x 19.7” (500 x 500mm)
- 34.3” x 31.5” x 36.6” (870 x 800 x 930mm)
- NST No. 40/NST No. 50
- 20~20,000rpm (#40), 35~12,000rpm (#50)
- 50 Pcs. (62,100,150,200 Opt.)
- 1.8 sec. /2.8 sec. (#40), 3.0 sec./7.0 sec. (#50)
- 2,362ipm (60m/min) x 12,000deg./min.
- 55KVA
40 Taper, 20,000rpm and #50 Taper, 12,000rpm spindle configurations. HSK spindle available as an option
Positioning Accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
Solid box way construction, linear scales on all axes and twin ballscrew design in the X & Y axes
Full 4th axis rotary table for 360ᴼ cutting capability
World's fastest rapid feed rates of 2,362ipm on solid box ways
Standard 2-station APC offers the ability to add pallets and pallet pool systems in the field
Beats the competition in work envelope size and stroke!
