- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 19.7” x 19.7” (500 x 500mm)
- 34.3” x 28” x 26” (870 x 710 x 660mm)
- NST No. 50
- 35~12,000rpm (20~8,000rpm Opt.)
- 50 Pcs. (100,150,200,300 Opt.)
- 2.5 sec. /5.5 sec.
- 1969ipm (50m/min) x 12,000deg/min
- 55KVA
Highest grade meehanite cast iron construction with solid box ways
Full 4th axis rotary table with high resolution rotary scale (Pos ±5 arc/sec)
Double decker style chip conveyor & internal hinge belt for exceptional chip evacuation
12,000rpm, gear driven dual contact spindle generates strong low end torque with fine finish capabilities
Patented twin ballscrew/twin servo motor driven axis drive system
Extra-large work envelope. Work piece diameter 31.5” x height 42.9”
2-station APC and 50 tool ATC – Both expandable in the field
