- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 24.8” x 24.8” (630 x 630mm)
- 41.34” x 33.46” x 35.43” (1,000 x 800 x 820mm)
- NST No. 50
- 35~12,000rpm (20~8,000rpm Opt.)
- 50 Pcs. (100,150,200,300 Opt.)
- 2.5 sec. /5.5 sec.
- 1969ipm (50m/min) x 12,000deg/min
- 55KVA
Flexibility with the ability to add 5th axis in the field
Patented twin ballscrew/twin servo motor driven axis drive system
Full 4th axis rotary table with high resolution rotary scale (Pos ±5 arc/sec)
RISC 64 bit processor with NURBS interpolation for higher processing speeds
Highest grade meehanite cast iron construction with solid box ways
Rigid 12,000rpm, gear driven, energy efficient, dual contact spindle
Positioning accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
