Super NTMX/NTMXL

BACK

World Premiere Twin ATC Machine ! Fusion between a 5-axismachining center and a lathe

  • Tool magazines on the left and right hand sides!
  • Distance between centers max.980mm/min.210mm
  • 48tools Number of stock tool (24x2)
  • 200mm Y-axis stroke (Tool spindle)
  • 12,000min-1 Milling speed (Tool spindle)
  • 7.5/3.7kW Built-in tool spindle motor
  • Up to 22kW cutting power available for turning shaft-work with synchronized spindles.(Left spindle motor 11/7.5kW、Right spindle motor 11/7.5kW)
  • 5.5/3.7kW Lower turrets Driven-tool motor
  • 230degree B-axis positioning range (±115degree)

    • Machine Specification

    Capacity
    Max.turning diameter

    200mm
    Max.turning lengtf 780mm
    Distance between centers

    max.980mm/min.210mm
    Bar capacity

    L,R: 51mm
    Chuck size L,R:165mm(6",)210mm（8"）
    Axis travel
    Slide travel X1/X2 570mm/130.5mm
    Slide travel Z1/Z2/B2-axis 1,297/658/770mm
    Slide travel Y ±100
    Left and Right spindles

    Spindle speed

    		5,000min-1
    L-spindle drive motor 11/7.5kW max.75.4N・m

    R-spindle drive motor

    		11/7.5kWmax. 75.4N・m
    Tool spindle
    Tool spindle speed 12,000min-1 (op.20,000min-1)
    Tool spindle drive motor 7.5/3.7kW　max.54N・m
    Tool shank type CAPTO C4
    Number of tool stock 48（24x2）
    Max.tool diameter/without adjacent tool 60mm/80mm

    Max.tool length /Max.tool weight

    		 180mm/4kg
    Indexing range 190°（±95°）
    Lower turret
    Type of turret head Dodecagonal drum turret

    Number of indexing positions

    		 24
    Tool size (square shank) □20mm
    Tool size (round shank) Φ25
    Spindle speed(op.) 6,000min-1
    Driven motor power and torque(op.) 7.1/2.2kW max.16N・m
    General
    Floor space（L×W×H） 4,225mm×3,015mm ×2,650mm
    Machine weight 14,500kg
    Capacity
      Φ51mm Φ65mm
    Max.turning diameter

    220mm
    Max.turning length 780mm
    Distance between centers

    max.980mm/min.210mm
    Bar capacity L/R 51mm

    65mm
    Chuck size L,R:165mm(6",)210mm（8"）
    Axis travel
    Slide travel X1/X2 570mm/130.5mm
    Slide travel Z1/Z2/B2-axis 1,637/998mm
    Slide travel /B2-axis 1110mm
    Slide travel Y ±100
    Left and Right spindles
    Spindle speed 5,000min-1 4,500min-1
    L-spindle drive motor 11/7.5kW

    R-spindle drive motor

    		11/7.5kW
    Tool spindle
    Tool spindle speed 12,000min-1 (op.20,000min-1)
    Tool spindle drive motor 11/7.5kW max.60N.m
    Tool shank type CAPTO C4(op.HSK-A40)
    Number of tool stock 48（24x2）
    Max.tool diameter/without adjacent tool 60mm/80mm

    Max.tool length /Max.tool weight

    		 180mm/4kg
    Indexing range 190°（±95°）
    Lower turret
    Type of turret head Dodecagonal drum turret

    Number of indexing positions

    		 24
    Tool size (square shank) □20mm
    Tool size (round shank) Φ25
    Spindle speed(op.) 6,000min-1
    Driven motor power and torque(op.) 7.1/2.2kW max.16N・m
    General
    Floor space（L×W×H） 5,806mm×3,138mm ×2,795mm
    Machine weight 16,500kg
