Innovative milling system contributes to realization of powerful cuts ever
Machine Specification
| Capacity | ||
|---|---|---|
| Max. turning diameter/Max. turning length | 410mm/530mm | |
| Distance between spindle nose | 757.8mm | |
| Bar capacity | 65mm | |
| Chuck size | 8" | |
| Axis travel | ||
Slide travel X |
277mm | |
| Slide travel Z | 580mm | |
| Slide travel Y（op.） | ±41mm | |
| Spindle | ||
| Spindle speed | 4,500min-1 | |
| Spindle motor | 11/7.5kW 248.1/210N.m | |
| Turret | ||
|---|---|---|
| Number of turrets | 1 | |
| Type of turret head/Number of index positions | Dodecagonal/24 | |
| Driven tools（op.） | ||
| Spindle speed | 6,000min-1 | |
| Driven motor power and torque | 7.5/3.7kW 40/16N.m | |
| Rotary system/Number of driven-tool stations | Individual rotation/12 | |
| Tailstock（op.） | ||
| Quill diameter/Quill stroke | 80mm/80mm | |
| Quill taper | MT-3（built-in center） | |
| General | ||
| Floor space （L×W×H） | 2,771mm×1,883.8mm ×1,964.6mm |
|
| Machine weight | 5,000kg | |
