Major improvement of the milling-unit,resulting in the higher rigidly
Innovative milling system "SuperMill" is equipped.
7.5/3.7kw 40N·m,High-power,High-torque Milling Motors on Upper and Lower Turrets
Opposed two-spindle, 2-turret construction!
Y-axis on Upper turrets ±35mm
48tools Number of tool stations
24tools Number of rotating tool stations
Up to 22kW cutting power available for turning shaft-work with synchronized spindles.(Left spindle motor 15/11kW、Right spindle motor 11/7.5kW)
Machine Specification
| Capacity |
| Max. turning diameter/Max. turning length |
190mm/400mm |
| Distance between spindle nose |
max.750mm/min.200mm |
| Bar capacity |
51mm 42mm（op.）65mm（op.）L only |
| Chuck size |
6"165mm |
| Axis travel |
| Slide travel X1/X2 |
157.5/167.5mm |
| Slide travel Z1/Z2/B2 |
465/465/550mm |
| Slide travel Y upper turret（op.） |
±35mm |
| Left spindle Right spindle |
| Spindle speed |
5,000min-1 6,000min-1（op.） 4,500min-1（op.） |
| Left spindle motor |
15/11kW 75.4/38.6N.m |
| Right spindle motor |
11/7.5kW 75.4/38.6N.m |
| Upper turret |
| Number of turrets |
1 |
| Spindle speed |
6,000min-1 3,600min-1 |
| Driven motor power and torque |
7.5/3.7kW 40/16N.m |
| Type of turret head/Number of index positions |
Dodecagonal/24 |
| Rotary system/Number of driven-tool stations |
Individual rotation/12 |
| Lower turret |
| Number of turrets |
1 |
| Spindle speed |
6,000min-1 3,600min-1 |
| Driven motor power and torque |
7.5/3.7kW 40/16N.m |
| Type of turret head/Number of index positions |
Dodecagonal/24 |
| Rotary system/Number of driven-tool stations |
Individual rotation/12 |
| General |
| Floor space （L×W×H） |
3,615mm×1,985mm
×1,860mm |
| Machine weight |
8,900kg |
