- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 16.1” x 35.4” (410 x 900mm)
- 30” x 18” x 18.1” (760 x 455 x 460mm)
- NST No. 40
- 40~15,000rpm
- 30 Pcs.
- 1.6 Sec. /3.3 Sec.
- 1,969ipm (50m/min) X/Y x 1,417ipm (36m/min) Z
- 30KVA
Enhanced control capability with Kitamura’s feature packed Arumatik-Mi control
Ideal for heavy duty cutting of molds to the high-speed accuracy cutting for high precision parts
Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
Rigid Meehanite cast iron construction with solid box ways
Versatile 15HP AC, 15,000rpm direct drive, dual contact spindle
Plumbed and ready for coolant thru the spindle – can be added in field
2,800 block/sec processing speeds for smoother and faster machining of complex work pieces
Flexibility with the ability to add 4th/5th axis in the field
