- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 50” x 25.2” (1,270 x 640mm)
- 43.31” x 24.02” x 24.02” (1,100 x 610 x 610mm)
- NST No. 50
- 10,000rpm
- 32 Pcs.
- 4.5 Sec. /7.0 Sec.
- 1,417ipm (36m/min) X/Y x 945ipm (24m/min) Z
- 35KVA
A 50" x 25.2" table and 43" x 24" x 24" travels beat the competition in capacity and stroke
Rigid solid box guideways incorporate a unique 4-slideway base construction for optimum rigidity
High speed rapids of 1417ipm (X&Y), 945ipm (Z) boosts work throughput
High power 10,000rpm, 35HP spindle delivers 662 N•m of spindle torque
Standard base wash system, internal chip augers and scraper type chip conveyor
Plumbed for coolant thru the spindle (220psi/1000psi option)
Additional axes implementation is an available option for optimum productivity
