- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 20.6” x 43.3” (522 x 1,100mm)
- 40” x 20” x 20” (1,016 x 510 x 510mm)
- NST No. 40, NST No. 50
- 40 Taper 20~15,000rpm (20~20,000rpm Opt.) 50 Taper 50~5,000rpm (20~10,000rpm Opt.)
- 30 Pcs. (40, 60 Opt.)
- 40Taper 1.2 Sec. /3.2 Sec., 50 Taper 2.5 Sec./8.0 Sec.
- 1,969ipm (50m/min) X/Y x 1,417ipm (36m/min) Z
- 35KVA
Ideal for machining larger size parts and molds
Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
Rigid Meehanite cast iron construction with solid box ways
Choice of #40 or #50 taper spindles for maximum machining flexibility
Standard 30-Tool ATC with 40 or 60 tools as available options
Flexibility with the ability to add 4th/5th axis in the field
Available with a 2-APC, high efficiency shuttle style pallet system
