Multi-tasking compact machine featuring state of all arts capabilities
Up to 22/15kW cutting power available for turning shaft-work with synchronized spindles.(Motor power 11/7.5kW per spindle)
Driven-Tool Motor Power 7.1/2.2kW,for heavy cutting with small tools.
With upper / lower turret construction,4-axis machining as well as various other machining combinations possible on either spindle
With upper / lower turrets and opposed two-spindle construction,cycle time balancing and reduction is possible.
With up to 24-tools per turret,48 tools can be permanently available.
Machine Specification
| Capacity |
| Max. turning diameter/Max. turning length |
190mm/503mm |
| Distance between spindle nose |
max.735mm/min.210mm |
| Bar capacity |
42mm |
| Chuck size |
6"165mm |
| Axis travel |
| Slide travel X1/X2 |
135/135mm |
| Slide travel Z1/Z2/B |
503/503/525mm |
| Slide travel Y upper turret |
±31mm |
| Left spindle Right spindle |
| Spindle speed |
6,000min-1 |
| Left spindle motor |
11/7.5kW 75.4/38.6N.m |
| Right spindle motor |
11/7.5kW 75.4/38.6N.m |
| Upper turret |
| Number of turrets |
1 |
| Spindle speed |
6,000min-1 |
| Type of turret head/Number of index positions |
Dodecagonal/24 |
| Driven motor power and torque |
7.1/2.2kW 16/8N.m |
| Rotary system/Number of driven-tool stations |
Individual rotation/12 |
| Lower turret |
| Number of turrets |
1 |
| Spindle speed |
6,000min-1 |
| Type of turret head/Number of index positions |
Dodecagonal/24 |
| Driven motor power and torque |
7.1/2.2kW 16/8N.m |
| Rotary system/Number of driven-tool stations |
Individual rotation/12 |
| General |
| Floor space （L×W×H） |
2,300mm×1,620mm
×1,940 |
| Machine weight |
5,650kg |
