WT-250II

BACK

Multi-purpose super machine for various type of parts,for small and large batches

  • Up to 29.5kW cutting power available for turning shaft-work with synchronized spindles.(Left spindle motor 18.5/15kW、Right spindle motor 11/7.5kW)
  • Driven-Tool Motor Power 5.5/3.7kW,for heavy cutting with small tools.
  • With upper / lower turret construction,4-axis machining as well as various other machining combinations possible on either spindle
  • With upper / lower turrets and opposed two-spindle construction,cycle time balancing and reduction is possible.
  • With up to 24-tools per turret,48 tools can be permanently available.

    • Machine Specification

    Capacity
    Max. turning diameter/Max. turning length 250mm/555mm
    Distance between spindle nose max.885mm/min.265mm
    Bar capacity L:65mm　R:51mm　R:65mm（op.）
    Chuck size 8"215mm　6"165mm
    Axis travel
    Slide travel X1/X2 195/195mm
    Slide travel Z1/Z2/B 600/600/620mm
    Slide travel Y upper turret ±41mm
    Left spindle Right spindleR
    Spindle speed L:φ65mm/4,500min-1
    R:φ51mm/5,000min-1
    R:φ65mm（op.）/4,500min-1
    Left spindle motor

    18.5/15kW

    （op.26/22kW・15/11kW wide range）
    Right spindle motor 11/7.5kW（op.15/11kW・18.5/15kW）
    Upper turret
    Number of turrets 1
    Spindle speed 6,000min-1
    Type of turret head/Number of index positions Dodecagonal/24
    Driven motor power 5.5/3.7kW
    Rotary system/Number of driven-tool stations Individual rotation/12
    Lower turret
    Number of turrets 1
    Spindle speed 6,000min-1
    Type of turret head/Number of index positions Dodecagonal/24
    Driven motor power and torque 5.5/3.7kW
    Rotary system/Number of driven-tool stations Individual rotation/12
    General
    Floor space （L×W×H） 4,059mm×2,314mm
    ×2,225mm
    Machine weight 8,700kg
