High Rigidity multi-tasking machine with box-type slides for all axes
Up to 30kW cutting power available for turning shaft-work with synchronized spindles.(Motor power 15/11kW per spindle)
Driven-Tool Motor Power 5.5/3.7kW,for heavy cutting with small tools.
With upper / lower turret construction,4-axis machining as well as various other machining combinations possible on either spindle
With upper / lower turrets and opposed two-spindle construction,cycle time balancing and reduction is possible.
With up to 24-tools per turret,48 tools can be permanently available.
Machine Specification
| Capacity |
| Max. turning diameter |
270mm 199mm/270mm |
| Max. turning length |
780mm |
| Distance between spindle nose |
max.1,100mm/min.250mm |
| Bar capacity |
65mm （op.L:102mm） |
| Chuck size |
8"/10" 12"305mm |
| Axis travel |
| Slide travel X1/X2 |
195/195mm 152.5mm/195mm |
| Slide travel Z1/Z2/B |
780/780/850mm |
| Slide travel Y upper turret |
±60mm ±40mm |
| Left spindle Right spindleR |
| Spindle speed |
4,500min-1 2,500min-1/L 4,500min-1/R |
| Left spindle motor |
15/11kW（op.18.5/15kW） |
| Right spindle motor |
15/11kW（op.18.5/15kW） |
| Upper turret |
| Number of turrets |
1 |
| Spindle speed |
3,600min-1 |
| Type of turret head/Number of index positions |
Dodecagonal/24 |
| Driven motor power and torque |
5.5/3.7kW 39.2/23.3N.m |
| Rotary system/Number of driven-tool stations |
Individual rotation/12 |
| Lower turret |
| Number of turrets |
1 |
| Spindle speed |
3,600min-1 |
| Type of turret head/Number of index positions |
Dodecagonal/24 |
| Driven motor power and torque |
5.5/3.7kW 39.2/23.3N.m |
| Rotary system/Number of driven-tool stations |
Individual rotation/12 |
| General |
| Floor space （L×W×H） |
4,230mm×2,518mm
×2,266mm |
| Machine weight |
14,000kg |
