Both turrets equipped with Y-axis

  • Opposed two-spindle,2-turret construction!
  • 48 tools Number of tool stations
  • 24 tools Number of driven-tool stations
  • 62mm Y-axis on 2-turret
  • 6000min-1 Driven-tool speed (Upper / Lower)
  • 11/7.5kW + 11/7.5kW L/R spindle motor
  • 7.1/2.2kWx3 Driven-tool motor (Upper / Lower)

    • Machine Specification

      φ42mm φ51mm φ65mm
    Capacity
    Max. turning diameter 175mm 200mm
    Max. turning length

    588mm

    		 570mm
    Distance between centers

    max.820mm/min.200mm
    Bar capacity

    42mm

    		 51mm 65mm
    Chuck size 165mm(6")
    Axis travel
    Slide travel X1/X2 135mm 150mm/141mm
    Slide travel Z1/Z2 588mm/578mm 570mm/560mm

    Slide travel Y1/Y2

    		 ±31mm ±32.5mm

    Left and right spindle
    Spindle speed 6,000min-1 5,000min-1 4,500min-1
    spindle drive motor L/R 11/7.5kW
    spindle drive motor L/R 75.4/38.6N・m 77/39.4N・m 80.9/41.4N・m
    Upper turrets
    Number of turrets 1
    Spindle speed 6,000min-1
    Driven motor power and torque 7.1/2.2kW　ｍａｘ．16N.m
    Type of turret head Dodecagonal
    Number of index positions 24
    Rotary system Individual rotation
    Number of driven-tool stations 12
    Lower turrets
    Number of turrets 1
    Spindle speed 6,000min-1
    Driven motor power and torque 7.1/2.2kW　max.　16N.m
    Type of turret head Dodecagonal
    Number of index positions 24
    Rotary system Individual rotation
    Number of driven-tool stations 12
    General
    Floor space H 2,395mm
    L 2,780mm
    W 2,070.5mm
    Machine weight 7,4000kg
