- Table Size:
- Travel (X, Y, Z):
- Spindle Taper:
- Spindle Speed:
- Tool Storage Capacity:
- Tool Change Time (T-T/C-C):
- Rapid Feed (X, Y, and Z x B):
- Power Requirement:
- 30.7” x 47.2” (780 x 1,200mm)
- 32” x 29.3” x 19.7” (815 x 745 x 500mm)
- NST No. 40
- 20~20,000rpm
- 50 Pcs. (100 Opt.)
- 2.5 Sec. /5.0 Sec.
- 984pm (25m/min)
- 35KVA
Ideal for ultra-high precision simultaneous 3-axis machining
Positioning Accuracy: ±0.000039” Full Stroke, Repeatability: ±0.00002”
Sliding overhead door allows for easy workpiece loading/unloading
Powerful 4-step geared spindle delivers high torque and high speed for maximum machining flexibility
Coolant thru the spindle, Oil mist spray and tool presetter are standard equipment
Linear scale feedback on all axes
Highest grade meehanite cast iron construction with solid box ways
